Hubsoft integration with Tysa

About Tysa

Tysa is a telecommunications, regulatory, and software company serving operators. Its consulting services cover licenses, interconnection, numbering, DETRAF, and number portability with operators, Anatel, and ABR Telecom. Its software suite for operators includes SBC, SIP-I interconnection, billing, STIR/SHAKEN, and number portability.

What the integration does

• Standard plan: plan synchronization creates the standard plan used to link numbers in the integration.
• Subscriber SIP account: each number linked to the customer's service is registered in Tysa. The provider defines whether the account is a regular account or SIP trunk and whether addressing is static or dynamic.
• Line rules: in the customer's service, you can define the SIP account password, call limit, line function (regular, key trunk, or DDR), and IP address when the line is a SIP trunk.
• Usage billing: Hubsoft retrieves the month's amounts from Tysa, displays the cost per number, and generates invoices or entries.
• Minimum charge: if the customer used less than the configured minimum, Hubsoft bills the minimum charge. The minimum can apply to the integration, a plan, or a customer.
• Who is included in billing: by default, only customers who made calls during the period. The provider can include all customers, exclude blocked customers, and exclude plan allowance amounts.
• Call details: optional, with the period's calls displayed on the customer's invoice.

What you need

• A contract with Tysa and API access details (address, username, and password), provided by Tysa itself.

How to activate

1. In Hubsoft, go to Configuration > Integration > STFC and click Add.
2. Enter the description, address, username, and password, then save.
3. Under Actions > Plans, click Synchronize Plans to create the standard plan.
4. In the customer's service, under Other Options > STFC Data, add the line parameters and number.
5. To bill, open Actions > Process/Bill, choose the entry type, month, and year, decide whether to include details, and load the processing.

The step-by-step guide with screenshots is available on the Tysa page in the Hubsoft wiki.

Limitations

• For a regular line, the IP address is fixed at 0.0.0.0. The IP address is only entered for a SIP trunk line.
• Hubsoft imports the amounts recorded in Tysa. If an amount is incorrect, it must be corrected on the platform.

Frequently asked questions

Can I charge a minimum fee for telephony?

Yes. Configure the minimum charge for the integration, a plan, or a customer. Customers who use less pay the minimum.

Is a customer who made no calls during the month included in billing?

By default, no. To include all customers with a number, enable the option to bill all customers.

I serve businesses with SIP trunks. Does the integration support them?

Yes. In the customer's service, set the account type to SIP trunk and enter the line's IP address.

Reviewed on 10/10/2026.
